Vertical Autoclave
Top Loading Vertical Autoclave & Sterilizers, ideal for small medical and research units
Vertical autoclaves are also known as steam sterilizers. Their primary function is to generate steam, create pressure and build up heat to sterilize medical tools, flasks, beakers and all other medical and research items which needs to be free from bacteria, viruses and all forms of organics.
iLabot Technologies is a vertical autoclave manufacturer from New Delhi, India. We are a 2 decade old company and we bring to you a wide range of vertical autoclaves. Our standard range includes a 22 ltr, 35 ltr, 70 ltr, 111ltr and 152 ltr options. These units are extensively used in hospitals and biotechnology laboratories. A vertical autoclave is manufactured in three different designs Economy model, Deluxe Model and Triple Walled. The difference between these models explained below:
Economy Model: In this economy vertical autoclave external surface is made of painted mild steel sheet and inner chamber is made of stainless steel. The lid is made of painted MS but inner part is made of stainless steel sheet. Pressure is controlled through automatic pressure switch.
Deluxe model: In Deluxe vertical autoclave, both inner chamber and external chamber are made of stainless steel and lid is also made of stainless steel. Radial locking system, ring and stand are made of chrome plate MS.
Triple Walled: Triple walled vertical autoclaves are highly effective sterilization equipment and considered most suitable for most of applications. These vertical autoclaves are made with three walls and all walls are made of stainless steel; while radial locking system, ring and stand are made from chrome plated MS. It has steam stock option, where steam is first generated in jacket and then transferred into sterilization chamber.
NOTE: We also undertake custom projects where we manufacture Vertical Autoclaves with custom specifications and dimensions.
Check out the technical specifications of Vertical Autoclaves manufactured by Ilabot Technologies
Vertical Autoclave: Technical Specifications |
||||
| Capacity | 35 Ltrs | 98 Ltrs | 152 Ltrs | |
| Chamber Dimension | 300 x 500mm | 450 x 600mm | 550 x 750mm | |
| Construction | SS 304 | SS 304 | SS 304 | |
| Power Consumption | 2 Kw | 6 Kw | 6 Kw | |
| Operating Pressure | 1.2 - 2.1 kg / cm2 | 1.2 - 2.1 kg / cm2 | 1.2 - 2.1 kg / cm2 | |
| Operating Temperature | 121째C | 121째C | 121째C | |
| Voltage | 220V AC | 220V AC | 220V AC | |
| Optional Accessories |
|
|||
| Download Brochure | ||||
KEY FEATURES
1. Stainless steel interior
2. Digital temperature indicator
3. Digital temperature Controller
4. ISI marked flange / immersion heating elements
5. Up to 121°C temperature range
6. Silicone rubber gasket
7. Automatic pressure control switch
8. Stainless steel basket
9. Reliable steam pressure gauges
10. Double or triple walled construction
11. Pedal for lid opening
12. Water level indicator
13. Water inlet & outlet valves
For your convenience, we are listing down the operational steps for easy assembly and use.
Steps to safely operate a Vertical Autoclave
1. Unlock the outer chamber by rotating the lock mechanism.
2. Open the lid by pressing the lift using your leg and rotate to place in lift mode.
3. Add sufficient level of water for steam generation.
4. Insert the inner chamber.
5. Place the items to be sterlized in the inner chamber.
6. Close the lid and turn the power on
7. Monitor change in temperature and pressure till desired levels have been achieved.
8. Release steam/pressure if necessary
9. Turn-off power once the process is complete and release the steam/pressure using the release valve.
10. Carefully remove the sterlized products.
Main Temperature Control: The Main Temperature Control consists of the digital display and UP and DOWN arrow pads for inputting set point temperatures and calibration of the autoclave machine.
Heating Lamp: This pilot lamp is ON when the unit is heating up to set point and is blinking when controlling temperature at set point.
Water level indicator: It is provided for indicating the water inside the chamber. It should not be more than it‘s mentioned level .
Safety valve: It provide for safety from high pressure condition. Safety valve becomes open when pressure of the chamber becomes high.
Pressure release valve: Use pressure release valve to release pressure of the chamber the horizontal autoclave after completion of work. It is a manual handle attached with system .
Water release valve: Use water release valve for releasing water from working chamber of the system.
Pressure gauge: It is pneumatic type pressure gauge. It is provided on front side of the machine for pressure display of working chamber.
Lift Pedal: Unlike their horizontal counterparts, pedal mechanism acts as a support to lift the heavy lid of the sterilizer.
Pressure Control Switch: Cut down the electrical connection when certain pressure reaches its set value inside the chamber.
In case, you have any questions, please let us know by contacting us via the contact number on our website or by submitting the query form.
CONTACT
Vertical Autoclave Price/Cost
Unlike traditional autoclaves which are big and take up a lot of space. Vertical Autoclaves are
easily to transport/move and are reasonably economical. Our Vertical Autoclaves range start at 48,000 INR + taxes.
In case you have a customized requirements, please fill up the contact form or call us on the number shared below, our team will get in touch and provide assistance pertaining to your queries and doubts. iLabot Technologies is a 2nd generation manufacturer and supplier of all types of autoclaves. Our range also includes Horizontal Autoclaves, Double Door Autoclaves,
Dental Autoclaves,
Cement Autoclaves and Portable/pressure cooker type autoclaves sterilizers and laboratory test equipment.
